Engine warmup
Thread Starter
Joined: Oct 2015
Posts: 279
Likes: 3
From: 43N
Engine warmup
Engine warm up if shut down for less than two hours is 2 minutes at idle, if shutdown for more than two hours warmup is 5 minutes at idle.
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Joined: Jul 2019
Posts: 16
Likes: 0
From: FL
Engine warm up if shut down for less than two hours is 2 minutes at idle, if shutdown for more than two hours warmup is 5 minutes at idle.
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Joined: Jan 2004
Posts: 1,068
Likes: 4
From: Hiding..... in one hemisphere or another
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Joined: Feb 2018
Posts: 800
Likes: 279
From: East of Westralia
Ask yourself what you are trying to achieve - a warm engine prior to takeoff.
If your manual states 5 minutes to warm up a “cold” engine, then unless you have run the engine for that long prior to shutting it down again, I’d suggest you start the warm up timer again on the next start. Be conservative.
I would be a little suspect of the reason for shutting it down again so soon after pushback, hypothetical aside.
If your manual states 5 minutes to warm up a “cold” engine, then unless you have run the engine for that long prior to shutting it down again, I’d suggest you start the warm up timer again on the next start. Be conservative.
I would be a little suspect of the reason for shutting it down again so soon after pushback, hypothetical aside.
Joined: Feb 2009
Posts: 945
Likes: 445
From: Austria
OP, as You did not mention the type or general situation you are referring to, maybe You could write a few words on why a shutdown after clearing of the congested area is necessary or beneficial? Are you taxiing out for departure or are you referring to a mere relocation of the aircraft on the apron that is for whatever reason done under its own power and not by tug?
One thing that needs to be remembered as well is that not only fuel costs money, but so does an engine. A startup is not exactly easy on the engine and it may well be that the additional maintenance costs due to the number of startup/shutdown cycles racked up by this practice will be way larger than the possible fuel and brake wear savings...
One thing that needs to be remembered as well is that not only fuel costs money, but so does an engine. A startup is not exactly easy on the engine and it may well be that the additional maintenance costs due to the number of startup/shutdown cycles racked up by this practice will be way larger than the possible fuel and brake wear savings...
Joined: Jan 2006
Posts: 2,205
Likes: 0
From: US
Probably close to zero, especially after viewing all the skid marks going around tight taxiway turns or lining up on the runway. The additional side load on the nose gear is minimal in comparison. The amount of corrective inputs by the rudder tiller to compensate for the asymmetrical thrust is minor.
Joined: Jan 2006
Posts: 2,205
Likes: 0
From: US
Thread Starter
Joined: Oct 2015
Posts: 279
Likes: 3
From: 43N
Several gate areas where we operate require a two engine taxi from the gate. After leaving the congested area, the taxi route can be 15 - 25 minutes, thus the engine shutdown. Monday I had a taxi which was 97 minutes gate to runway. How about a show of hands who would run two engines during that length of taxi. Once during that taxi we even shut down both engines for about 20 minutes, think of that. Then, to top it all off, we did a cross bleed to start number two.
Our outfits bean counters have run the numbers and have determined any engine shutdown, regardless of length, is money saving. I fly airplanes, the bean counters count beans, if that’s what they have determined that’s good enough for me. To those of you who have provided a thoughtful response, thanks.
Our outfits bean counters have run the numbers and have determined any engine shutdown, regardless of length, is money saving. I fly airplanes, the bean counters count beans, if that’s what they have determined that’s good enough for me. To those of you who have provided a thoughtful response, thanks.
Joined: Mar 2006
Posts: 2,633
Likes: 137
From: USA
I don't consider 20 minutes a long time at all. I'd keep them both running. Having the PTU or yellow pump running is incredibly annoying from a passenger perspective, particularly for those seated nearest to those pumps (A320).
Obviously for a 90 minute taxi at JFK, I'd consider shutting one down, but again, the noise in the cabin for that length of time may give me pause. If I know the taxi will be that long, I'll request extra fuel. We may be too heavy to make a SE taxi practical anyway.
Obviously for a 90 minute taxi at JFK, I'd consider shutting one down, but again, the noise in the cabin for that length of time may give me pause. If I know the taxi will be that long, I'll request extra fuel. We may be too heavy to make a SE taxi practical anyway.
Only half a speed-brake
Joined: Apr 2003
Posts: 4,459
Likes: 136
From: Commuting not home
Get a tug to pull you out a bit.
According to a knowledgeable CFM gentleman, up to 15 minutes warmup is still beneficial to the longevity of the engine, which translates well into direct fuel savings due to low(er) burn for long(er) time.
Though I understand you speak of IAE engines, which at least on the small bus really have a lot of ground idle thrust, pitty you cannot make it out on just one.
Towards the core of your question, I have nothing to add. It is an odd situation hence you came here with it. The suggestion with a tug is serious - beancounter's business as you have already pointed out.
According to a knowledgeable CFM gentleman, up to 15 minutes warmup is still beneficial to the longevity of the engine, which translates well into direct fuel savings due to low(er) burn for long(er) time.
Though I understand you speak of IAE engines, which at least on the small bus really have a lot of ground idle thrust, pitty you cannot make it out on just one.
Towards the core of your question, I have nothing to add. It is an odd situation hence you came here with it. The suggestion with a tug is serious - beancounter's business as you have already pointed out.
Joined: Jul 2013
Aviation Qualifications: Non-Aircrew
Posts: 5,682
Likes: 3,346
From: Everett, WA
I thought I posted this earlier, but it didn't show up so I'll risk repeating myself.
The bottom line is that running at/near idle for a few minutes then shutting down for 90 minutes does not meet the requirements for having a 'warm' engine. Perform a minimum of a five minute warmup.
Setting takeoff power on an engine that isn't thermally stable is hard on the engine. The impact can be anything from a tip seal rub (permanent performance loss) to in extreme cases it can cause an engine surge.
Saving a couple of gallons of fuel by not doing a proper warmup will be quickly swamped by even a small increase in engine fuel burn until the next overhaul.
The bottom line is that running at/near idle for a few minutes then shutting down for 90 minutes does not meet the requirements for having a 'warm' engine. Perform a minimum of a five minute warmup.
Setting takeoff power on an engine that isn't thermally stable is hard on the engine. The impact can be anything from a tip seal rub (permanent performance loss) to in extreme cases it can cause an engine surge.
Saving a couple of gallons of fuel by not doing a proper warmup will be quickly swamped by even a small increase in engine fuel burn until the next overhaul.
Joined: Mar 2006
Posts: 2,633
Likes: 137
From: USA
I thought I posted this earlier, but it didn't show up so I'll risk repeating myself.
The bottom line is that running at/near idle for a few minutes then shutting down for 90 minutes does not meet the requirements for having a 'warm' engine. Perform a minimum of a five minute warmup.
Setting takeoff power on an engine that isn't thermally stable is hard on the engine. The impact can be anything from a tip seal rub (permanent performance loss) to in extreme cases it can cause an engine surge.
Saving a couple of gallons of fuel by not doing a proper warmup will be quickly swamped by even a small increase in engine fuel burn until the next overhaul.
The bottom line is that running at/near idle for a few minutes then shutting down for 90 minutes does not meet the requirements for having a 'warm' engine. Perform a minimum of a five minute warmup.
Setting takeoff power on an engine that isn't thermally stable is hard on the engine. The impact can be anything from a tip seal rub (permanent performance loss) to in extreme cases it can cause an engine surge.
Saving a couple of gallons of fuel by not doing a proper warmup will be quickly swamped by even a small increase in engine fuel burn until the next overhaul.
Thanks as always for your insightful contribution.
I've flown with people who must pride themselves in applying takeoff thrust and shutting down the engine right at the limits. Never understood it.
Last edited by Check Airman; 1st August 2019 at 03:02.
Joined: Nov 1999
Aviation Qualifications: ATPL
Posts: 3,150
Likes: 744
From: UK
Mechanical sympathy applies.
I once got to the staff carpark at the same time as a group of ground handlers. They obviously had some sort of private race going on, or were trying to beat the traffic. They each started their car engines and as soon as the engines caught, they all accelerated away like mad things.
Every one of their engines sounded like a bucket of bolts, i.e. worn to buggery because of working the engines hard before the oil was warm enough to circulate fully. Now, think of a gas turbine engine, parts of which are under much higher stress than a car engine, especially at take-off power.
As well as seals, and thermal stresses within the engine, the oil needs to be warm enough and fluid enough to get around the engine easily and quickly.
I once got to the staff carpark at the same time as a group of ground handlers. They obviously had some sort of private race going on, or were trying to beat the traffic. They each started their car engines and as soon as the engines caught, they all accelerated away like mad things.
Every one of their engines sounded like a bucket of bolts, i.e. worn to buggery because of working the engines hard before the oil was warm enough to circulate fully. Now, think of a gas turbine engine, parts of which are under much higher stress than a car engine, especially at take-off power.
As well as seals, and thermal stresses within the engine, the oil needs to be warm enough and fluid enough to get around the engine easily and quickly.
Joined: Feb 2009
Posts: 945
Likes: 445
From: Austria
Even at the risk of some thread drift:
Now, the operational area I am familiar with is Europe and its closer surroundings, and I may not have come across the yet unmentioned airport that this took place on. However, this does strike me as exceptionally long - possibly longer than the subsequent flight. Does ATC allow startup and pushback without taking runway queues into account? Is there no CDM or "first come-first serve" queue along which startups are approved while both allowing sufficient taxi time and keeping the queues at the holding point somewhat within a reasonable limit?
Surely, such a system would be desirable from an efficiency, fuel saving and engine lifetime saving standpoint and beneficient to ATC and airlines alike? If you are not going to depart for another 90 minutes, why not wait at some parking spot with, possibly a remote one, with ground power and aircondition plugged in?
Originally Posted by CaptainMongo
Monday I had a taxi which was 97 minutes gate to runway.
Surely, such a system would be desirable from an efficiency, fuel saving and engine lifetime saving standpoint and beneficient to ATC and airlines alike? If you are not going to depart for another 90 minutes, why not wait at some parking spot with, possibly a remote one, with ground power and aircondition plugged in?
Joined: Nov 2005
Posts: 729
Likes: 1
From: Zulu Time Zone
Engine warm up if shut down for less than two hours is 2 minutes at idle, if shutdown for more than two hours warmup is 5 minutes at idle.
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
Scenario: Engines have been shut down for 3 hours. Push back from gate, start both engines because it is required for initial taxi. After clear of congested area, shut down engine two (it has been running for less than 2 minutes) and continue taxi. What will be the warm up required upon restart of engine 2?
