PS about the crashed AOA sensors.
No troubleshooting will be possible. They are outside, they are on the nose (outside cockpit area) => Ever seen an AOA vane that hit the deck at 400 kts?
No troubleshooting will be possible. They are outside, they are on the nose (outside cockpit area) => Ever seen an AOA vane that hit the deck at 400 kts?
Join Date: Nov 2000
Location: Canada
Posts: 603
Likes: 0
Received 0 Likes
on
0 Posts
Sorry if I missed this question:
! wonder how many times the MCAS system activated and kept aircraft safe? Would the aircraft be safe without the system and if not, there in lies the problem.
! wonder how many times the MCAS system activated and kept aircraft safe? Would the aircraft be safe without the system and if not, there in lies the problem.
Join Date: Apr 2008
Location: Paris
Age: 74
Posts: 275
Likes: 0
Received 0 Likes
on
0 Posts
Why not have an emergency override switch that allows pilots to command the stabiliser RAPIDLY to a precise target position? Or one of a few conveniently spaced positions within its total excursion?
That way if MCAS does something unwanted, or other issues arrive that make fast manual retriming desirable the pilots just select the desired target position and get back to sanity ...
Edmund
That way if MCAS does something unwanted, or other issues arrive that make fast manual retriming desirable the pilots just select the desired target position and get back to sanity ...
Edmund
Why not have an emergency override switch that allows pilots to command the stabiliser RAPIDLY to a precise target position? Or one of a few conveniently spaced positions within its total excursion?
That way if MCAS does something unwanted, or other issues arrive that make fast manual retriming desirable the pilots just select the desired target position and get back to sanity ...
Edmund
That way if MCAS does something unwanted, or other issues arrive that make fast manual retriming desirable the pilots just select the desired target position and get back to sanity ...
Edmund
Join Date: Dec 2015
Location: Cape Town, ZA
Age: 62
Posts: 424
Likes: 0
Received 0 Likes
on
0 Posts
Ironically this is exactly the outcome of the MCAS system. Trying to add another fix, to counter the problem created by MCAS, is the height of absurdity. Sorry if that is too blunt!
Join Date: Nov 2018
Location: madrid
Posts: 47
Likes: 0
Received 0 Likes
on
0 Posts
As others have stated repeatedly: Adding complexity to an inherently reliable system does not enhance safety. On the contrary, it is likely to introduce new and unanticipated failure modes.
Ironically this is exactly the outcome of the MCAS system. Trying to add another fix, to counter the problem created by MCAS, is the height of absurdity. Sorry if that is too blunt!
Ironically this is exactly the outcome of the MCAS system. Trying to add another fix, to counter the problem created by MCAS, is the height of absurdity. Sorry if that is too blunt!
Technically, the most practical solution would be to completely delete mcas and upgrade the stall feel mechanism from on/off to gradual. One little box involved, possibility of mayhem kept the same (very low), feel improved also in real life scenarios, requirement passed.
(For those like me looking for an elegant solution: Tiny fixed lift devices (vanes) at the lower sides of the plane near the tail (cirrus vision style) are not hard to tune to be lift neutral or even generating a bit of downforce at low aoa but increase its contribution to the pitch down moment by adding lift quicker than the stabilizer as aoa increases (thats the key, otherwise simply enlarging the stabilizer 1% would do). But this system would retain the fundamental MCAS fault: it will perhaps only work at one range of load factors, perfect for certification, not so perfect for real life).
Bureaucratically who knows what makes sense now.
to the point
Join Date: Dec 2015
Location: Cape Town, ZA
Age: 62
Posts: 424
Likes: 0
Received 0 Likes
on
0 Posts
Also see posts #2730-2732 and 2734 Ethiopian airliner down in Africa
This story seems to be unraveling quickly this week, reflecting badly on both Boeing and the regulators, but giving us (non-experts) a lot more clarity on how/why/when/where/what. Pity we had to have two crashes to find this all out...
Last edited by GordonR_Cape; 29th Mar 2019 at 13:34.
Join Date: Dec 2011
Location: Ottawa, Canada
Posts: 28
Likes: 0
Received 0 Likes
on
0 Posts
The 737Max has an uncertifiable characteristic whereby elevator control force decreases as AoA increases towards stall. It is stated that this is the sole reason for MCAS.
The 737 has an Elevator Feel Computer whose purpose is to increase elevator control force as airspeed increases. The control forces are applied hydraulically and are separate from Speed Trim System whose function is to maintain control force neutral.
Is there a simple reason why the EFC could not have been provided with an AoA proportional input so that this existing system could compensate for the control force reversal?
MCAS as a solution is a brutal method of stick force compensation. When operating it almost makes the aircraft impossible to stall. One might wonder what the Max stall characteristics are like.
Or am I being too cycnical?
The 737 has an Elevator Feel Computer whose purpose is to increase elevator control force as airspeed increases. The control forces are applied hydraulically and are separate from Speed Trim System whose function is to maintain control force neutral.
Is there a simple reason why the EFC could not have been provided with an AoA proportional input so that this existing system could compensate for the control force reversal?
MCAS as a solution is a brutal method of stick force compensation. When operating it almost makes the aircraft impossible to stall. One might wonder what the Max stall characteristics are like.
Or am I being too cycnical?
Last edited by ktcanuck; 29th Mar 2019 at 14:55.
Join Date: Apr 2013
Location: Neither here or there
Posts: 317
Likes: 0
Received 0 Likes
on
0 Posts
Presumably MCAS (a requirement for certification) doesn't appear in the MEL? Meaning, if it's broken or compromised, no pilot would ever know about it and therefore be at the mercy of luck in case they encountered a high AoA situation...The mind boggles.
Join Date: Dec 2015
Location: Cape Town, ZA
Age: 62
Posts: 424
Likes: 0
Received 0 Likes
on
0 Posts
ktcanuck
That question was comprehensively answered a few pages back in this thread. The elevator feel computer does not have enough hydraulic power to generate the feedback forces for certification: Boeing 737 Max Software Fixes Due to Lion Air Crash Delayed
The 737 has an Elevator Feel Computer whose purpose is to increase elevator control force as airspeed increases. The control forces are applied hydraulically and are separate from Speed Trim System whose function is to maintain control force neutral.
Is there a simple reason why the EFC could not have been provided with an AoA proportional input so that this existing system could compensate for the control force reversal?
Is there a simple reason why the EFC could not have been provided with an AoA proportional input so that this existing system could compensate for the control force reversal?
2. There is not enough column / elevator feel system adjustment range to provide the compensation that would be needed. This is particularly true at high Mach / speed where the nominal setting for the feel system is rather high to begin with. There is not enough range left in the system from there to max pressure to sufficiently offset the Cm-alpha characteristic that must be addressed to meet the FARs.
Join Date: Dec 2011
Location: Ottawa, Canada
Posts: 28
Likes: 0
Received 0 Likes
on
0 Posts
[QUOTE=GordonR_Cape;10433552]ktcanuck
That question was comprehensively answered a few pages back in this thread. The elevator feel computer does not have enough hydraulic power to generate the feedback forces for certification: /QUOTE]
My apologies. I thought I was following this thread comprehensively!
That question was comprehensively answered a few pages back in this thread. The elevator feel computer does not have enough hydraulic power to generate the feedback forces for certification: /QUOTE]
My apologies. I thought I was following this thread comprehensively!
Join Date: Mar 2015
Location: North by Northwest
Posts: 476
Likes: 0
Received 0 Likes
on
0 Posts
Thanks. I missed that whole page (sometimes happens when there are multiple updates and thread renumbering at the same time). Edit: Posts that were held back for moderation and suddenly appear in the thread, also increment the counter.
This story seems to be unraveling quickly this week, reflecting badly on both Boeing and the regulators, but giving us (non-experts) a lot more clarity on how/why/when/where/what. Pity we had to have two crashes to find this all out...
This story seems to be unraveling quickly this week, reflecting badly on both Boeing and the regulators, but giving us (non-experts) a lot more clarity on how/why/when/where/what. Pity we had to have two crashes to find this all out...
Well, would appear to be accurate.
http://www.airforcemag.com/Features/...AS-System.aspx
Join Date: May 2017
Location: San Diego
Posts: 66
Likes: 0
Received 0 Likes
on
0 Posts
They didn't need to turn it off. Not stalling. Pitch was high, yet with an empty aircraft, velocity vector was high too.
It does raise a related issue: What pitch angle and/or vertical speed should MCAS be safely disabled?
I might have implemented a disable for pitch angle < 6 degrees, and possibly add an AND condtion with vertical speed < 0 which would keep the nose from auto-trimming down when descending at a low or negative pitch angle.
What condition would you disable MCAS down-trim on? Boeing isn't buying any of that of course, yet doesn't keep us from suggesting something else.
It does raise a related issue: What pitch angle and/or vertical speed should MCAS be safely disabled?
I might have implemented a disable for pitch angle < 6 degrees, and possibly add an AND condtion with vertical speed < 0 which would keep the nose from auto-trimming down when descending at a low or negative pitch angle.
What condition would you disable MCAS down-trim on? Boeing isn't buying any of that of course, yet doesn't keep us from suggesting something else.
Join Date: Dec 2015
Location: Cape Town, ZA
Age: 62
Posts: 424
Likes: 0
Received 0 Likes
on
0 Posts
Interesting assertion in a 737NG pilot's YT video - the KC-46 also has an MCAS-like system but it relies on input from both alpha vanes and disconnects on opposite control column input. Big difference in CG I understand but if true, why would Boeing not carry the same philosophy over to the MAX?
Well, would appear to be accurate.
Air Force Magazine
Well, would appear to be accurate.
Air Force Magazine
https://aviationweek.com/defense/boe...d-pitch-system
Boeing 737 Max Software Fixes Due to Lion Air Crash Delayed
Last edited by GordonR_Cape; 30th Mar 2019 at 04:55. Reason: Typo.
Join Date: Nov 2018
Location: madrid
Posts: 47
Likes: 0
Received 0 Likes
on
0 Posts
They didn't need to turn it off. Not stalling. Pitch was high, yet with an empty aircraft, velocity vector was high too.
It does raise a related issue: What pitch angle and/or vertical speed should MCAS be safely disabled?
I might have implemented a disable for pitch angle < 6 degrees, and possibly add an AND condtion with vertical speed < 0 which would keep the nose from auto-trimming down when descending at a low or negative pitch angle.
What condition would you disable MCAS down-trim on? Boeing isn't buying any of that of course, yet doesn't keep us from suggesting something else.
It does raise a related issue: What pitch angle and/or vertical speed should MCAS be safely disabled?
I might have implemented a disable for pitch angle < 6 degrees, and possibly add an AND condtion with vertical speed < 0 which would keep the nose from auto-trimming down when descending at a low or negative pitch angle.
What condition would you disable MCAS down-trim on? Boeing isn't buying any of that of course, yet doesn't keep us from suggesting something else.
And for those suggesting that artificial feel is not powerful enough, I don't agree, it makes one sweat if it goes haywire, does it not. That's not the problem, the problem is that it uses all its power in some circumstances now so it would be saturated if we superposed a new one. (And if it wouldn't, it would be too strong to physically overcome anyway).
Obvious solution: we would need to reduce the feel by a factor of 0.8 across all range and then use the new 20% headroom for MCAS. The rule is concerned about the linearity, I am almost sure that the feel in the 737 has a lot of margin to be softened.
I'm talking a fairly small double sided cylinder with 20% more area in the downstream side, feel computer connected to one chamber, feel swinging assembly to the other; and a big ass solenoid to supplement the pressure in the event of an MCAS event. One for each feel hydraulic circuit.
The feel "computer" (impressive bunch of pistons and springs and little pipes) would not need upgrading. And feel system is always possible to handle if something goes completely wrong (remember it is a peculiar system, force is always zero in the center by design).
Still I would prefer an aero solution like the vanes described before, it would involve much harder design but much easier retrofit.
Join Date: Aug 2006
Location: cardiff
Posts: 598
Likes: 0
Received 0 Likes
on
0 Posts
From posts elsewhere, it would appear to be a sub routine of the Flight Control Computer ergo any MEL alleviation would be listed against the said Flight Control Computer, if no MEL listing for FCC, then it is non-despatchable.
