Hanscom G-IV Crash - NTSB probable cause
How does a professional crew with a combined 29000+ hours and flying together for 12 years get into a routine of "habitual noncompliance with checklists"?
http://www.ntsb.gov/news/press-relea...R20150909.aspx
http://www.ntsb.gov/news/press-relea...R20150909.aspx
flying together for 12 years
Human factors, you get too 'comfortable' with each other.
This is troubling:
However, the investigation revealed that Gulfstream did not ensure that the gust lock system would sufficiently limit the throttle movement on the G-IV airplane, which allowed the pilots of the accident flight to accelerate the airplane to takeoff speed before they discovered that the flight controls were locked
The NTSB said that the Federal Aviation Administration’s certification of the gust lock system was inadequate because it did not require Gulfstream to perform any engineering certification tests or analysis of the G-IV gust lock system to verify that the system had met its regulatory requirements.
Also contributing to the accident were Gulfstream’s failure to ensure that the gust lock system would prevent an attempted takeoff with the gust lock engaged and the FAA’s failure to detect this inadequacy during the G-IV’s certification.
Continue when locked?
Not a pilot, but a former reliability guy for the major microprocessor manufacturer, and well aware that routine checks can get skipped by human beings who don't think they'll ever catch anything. But I'm genuinely puzzled by this:
My guess it that despite the recorded comment, somehow internally there was some combination of disbelief and of "success orientation", but that is a pretty wild guess.
About 26 seconds into the takeoff roll, when the airplane had reached a speed of 148 mph (129 kts), the pilot in command indicated that the flight controls were locked, but the crew did not begin to apply the brakes for another 10 seconds and did not reduce engine power until four more seconds had passed.
Hanscom G-IV Crash - NTSB probable cause
Quick question: is the a way to unlock the flight control from the cockpit? Would that be an option instead of rejecting the take off?
Join Date: May 2001
Location: HERE AND THERE
Posts: 863
Likes: 0
Received 0 Likes
on
0 Posts
Attack
There is: if you read the NTSB report you'd learn that the system incorporates a feature supposed to prevent the throttles to be advanced with flight controls locked. It simply didn't performed as supposed to.
What you suggest would be expensive and/or difficult to certificate.
Furthermore, it's impossible to design an airplane that protect itself from pilots displaying a complete lack of airmanship.
What you suggest would be expensive and/or difficult to certificate.
Furthermore, it's impossible to design an airplane that protect itself from pilots displaying a complete lack of airmanship.
Hanscom G-IV Crash - NTSB probable cause
Sorry maybe I did not spell out my question correctly. I understand that the built in safeguard has failed here. My question was more: was there another option to the (late) RTO ? Could they have taken the aircraft into the air after having the flight control unlocked ?
Join Date: Sep 2014
Location: Canada
Posts: 1,257
Likes: 0
Received 0 Likes
on
0 Posts
Could they have taken the aircraft into the air after having the flight control unlocked ?
So normally the gust lock must be released early in the checklist, when the hydraulic system still unpressurized before the engine is started. Otherwise the gust lock will remain engaged until the engines are shut off again and hydraulic pressure is removed.
There is a Flight Power Shut-off Valve (FPSOV) which can be pulled in an emergency in case there is a jam in the hydraulic system. The FPSOV will relieve the hydraulic pressure. It can also be used as an unapproved way to disengage the gust lock once engines have been started (e.g., during taxi).
There's evidence that the crew pulled the FPSOV. But, it is not known if pulling the FPSOV during a take-off run will successfully disengage the gust lock, because now we're dealing with aerodynamic pressures loading on the flight controls, in addition to the hydraulic pressure.
"the pilot in command indicated that the flight controls were locked, but the crew did not begin to apply the brakes for another 10 seconds and did not reduce engine power until four more seconds had passed."
My guess it that despite the recorded comment, somehow internally there was some combination of disbelief and of "success orientation", but that is a pretty wild guess.
My guess it that despite the recorded comment, somehow internally there was some combination of disbelief and of "success orientation", but that is a pretty wild guess.
Another reason is they might have initially thought that they were having a power hydraulics issue and so they tried to solve it by pulling on the FPSOV handle (as above) and tugging on the flight controls.
Pulling the FPSOV also disabled the ability to deploy the spoilers didn't it? That didn't help in the reject attempt.
The biggest issue is the lack of control checks. Whilst there may well indeed have been a fault/flaw with the gust lock mechanism which may have actually engaged as they started rolling down the runway- IF the crew had of been more professional and done a successful FULL control check prior to that takeoff I would expect that at the first sign of lack of control when barrelling down the runway their decisions and actions would have been different. I know mine would... Let's see I just did a successful control check before applying takeoff power, now my elevators are jammed and the lock is on and not releasing. No hope of getting airborne let's abort!
The biggest issue is the lack of control checks. Whilst there may well indeed have been a fault/flaw with the gust lock mechanism which may have actually engaged as they started rolling down the runway- IF the crew had of been more professional and done a successful FULL control check prior to that takeoff I would expect that at the first sign of lack of control when barrelling down the runway their decisions and actions would have been different. I know mine would... Let's see I just did a successful control check before applying takeoff power, now my elevators are jammed and the lock is on and not releasing. No hope of getting airborne let's abort!
Control Checks
This poor practice and lack of knowledge is unfortunately not uncommon.
Not too long a go I was flying for a European scheduled airline as a line training and checking captain where I routinely saw the FOs do the control checks then if it was windy put the control locks back in. They would rely on memory to remove them before take off but never considered doing another control check.
The fact that I saw many different FOs do this indicates that it was normal practice in the airline which was also backed up by my questioning of the crews. They also saw nothing wrong with it and considered it to be normal practice. Believe it or not a couple even thought I was being awkward by insisting on a control check every time the locks were removed.
This unfortunately happens when small isolated groups of people do not either have or seek outside input to their operation.
MM
Not too long a go I was flying for a European scheduled airline as a line training and checking captain where I routinely saw the FOs do the control checks then if it was windy put the control locks back in. They would rely on memory to remove them before take off but never considered doing another control check.
The fact that I saw many different FOs do this indicates that it was normal practice in the airline which was also backed up by my questioning of the crews. They also saw nothing wrong with it and considered it to be normal practice. Believe it or not a couple even thought I was being awkward by insisting on a control check every time the locks were removed.
This unfortunately happens when small isolated groups of people do not either have or seek outside input to their operation.
MM
Join Date: Jun 2000
Location: last time I looked I was still here.
Posts: 4,507
Likes: 0
Received 0 Likes
on
0 Posts
So normally the gust lock must be released early in the checklist, when the hydraulic system still unpressurized before the engine is started. Otherwise the gust lock will remain engaged until the engines are shut off again and hydraulic pressure is removed.
This strikes as a classic case for having a takeoff configuration warning horn fitted, as per most airliners. This would act as a back up to the other system preventing takeoff power being selected, which didn't work.
Part of the reason is that they did not discover the issue until after v1, when they attempted to rotate. Pilots are trained with the mindset that problems before v1 == rejected take-off, while anything > v1 means continuing the flight.
At the end of the takeoff/RTO brief it usually goes on the "or if the a/c is unsafe to fly." Even if >V1 this scenario seems to fit into this category. How long was the runway? On longer than required runways stopping after V1 is often not a problem; if you react soon enough. There might have been a moment of astonished disbelief frozen in the headlights phobia.
This strikes as a classic case for having a takeoff configuration warning horn fitted, as per most airliners. This would act as a back up to the other system preventing takeoff power being selected, which didn't work.
Part of the reason is that they did not discover the issue until after v1, when they attempted to rotate. Pilots are trained with the mindset that problems before v1 == rejected take-off, while anything > v1 means continuing the flight.
At the end of the takeoff/RTO brief it usually goes on the "or if the a/c is unsafe to fly." Even if >V1 this scenario seems to fit into this category. How long was the runway? On longer than required runways stopping after V1 is often not a problem; if you react soon enough. There might have been a moment of astonished disbelief frozen in the headlights phobia.
Join Date: Jul 2010
Location: El Dorado
Posts: 162
Likes: 0
Received 0 Likes
on
0 Posts
Also contributing to the accident were Gulfstream’s failure to ensure that the gust lock system would prevent an attempted takeoff with the gust lock engaged and the FAA’s failure to detect this inadequacy during the G-IV’s certification.
Join Date: Apr 2009
Location: Oakland, CA
Age: 72
Posts: 427
Likes: 0
Received 0 Likes
on
0 Posts
Excessively harsh comment and i take offense to it.
"A review of the flight crew’s previous 175 flights revealed that the pilots had performed complete preflight control checks on only two of them. The flight crew’s habitual noncompliance with checklists was a contributing factor to the accident.”
Join Date: Jun 2013
Location: Or-E-Gun, USA
Posts: 326
Likes: 0
Received 0 Likes
on
0 Posts
Easy Answer? No Such Thing
As others properly note, they got into this situation for exactly the reasons that the thread opener asks. High-time, long personal association, long experience on type (probably the same specific aircraft) and the like. Habits like these are nearly impossible to break and comments like, "We always do it this way," and "We know this airplane inside and out," are not rare.
One of the genuine hallmarks of the 'real' professional is to assume nothing and conduct the inspections and setups from scratch, Every Single Time. As this situation demonstrates, super-efficiency and perhaps saving a whopping five minutes is never worth the risk.
I do not know how to break that mold, but I hope someone figures out a good way to do so.
I must add that I do NOT understand how/why any pilot would/could release brakes without first performing a full range control surfaces test. If the results dictate a shutdown and further inquiry, so what? Even a C172 student pilot understands that one cannot control an airplane with locked controls - and V1 is darn sure not the place to discover the problem. Ouch!
One of the genuine hallmarks of the 'real' professional is to assume nothing and conduct the inspections and setups from scratch, Every Single Time. As this situation demonstrates, super-efficiency and perhaps saving a whopping five minutes is never worth the risk.
I do not know how to break that mold, but I hope someone figures out a good way to do so.
I must add that I do NOT understand how/why any pilot would/could release brakes without first performing a full range control surfaces test. If the results dictate a shutdown and further inquiry, so what? Even a C172 student pilot understands that one cannot control an airplane with locked controls - and V1 is darn sure not the place to discover the problem. Ouch!
Last edited by No Fly Zone; 12th Sep 2015 at 17:30. Reason: Addendum
Screw AOPA, that comment si from the NTSB report.
In any case, Let him who is without sin cast the first stone comes to mind.
This is why an accident seldom has a single cause.
I don't, the comment is justified in view of this...
- The crew failed
- The airplane failed
- Gulfstream failed
- The FAA failed
This is why an accident seldom has a single cause.
Join Date: Jun 2000
Location: last time I looked I was still here.
Posts: 4,507
Likes: 0
Received 0 Likes
on
0 Posts
The crew failed
The airplane failed
Gulfstream failed
The FAA failed
And what % of causal blame do you attribute to each? It would seem your list is in reverse order of occurrence, slightly. I'd put FAA at No.2., but still reverse order.
The airplane failed
Gulfstream failed
The FAA failed
And what % of causal blame do you attribute to each? It would seem your list is in reverse order of occurrence, slightly. I'd put FAA at No.2., but still reverse order.
Join Date: Mar 2004
Location: schermoney and left front seat
Age: 57
Posts: 2,438
Received 0 Likes
on
0 Posts
This unfortunately happens when small isolated groups of people do not either have or seek outside input to their operation.
Join Date: Jan 2009
Location: Earth
Posts: 74
Likes: 0
Received 0 Likes
on
0 Posts
See also my post in the GA Forum thread on the KBED accident (below). Such a shame that the crew realized a problem early on per the NTSB video but by the time they took action to stop, it was too late.
http://www.pprune.org/biz-jets-ag-fl...ml#post9111459
http://www.pprune.org/biz-jets-ag-fl...ml#post9111459
Last edited by Feathered; 13th Sep 2015 at 07:30.
100%
And what % of causal blame do you attribute to each? It would seem your list is in reverse order of occurrence, slightly. I'd put FAA at No.2., but still reverse order.
Join Date: Jul 2010
Location: El Dorado
Posts: 162
Likes: 0
Received 0 Likes
on
0 Posts
This is why an accident seldom has a single cause.
